Fluke 87-5 Multimeter (87-V) True RMS with Temperature

Accuracy and diagnostic functions for maximum industrial productivity The new 87-V has improved measurement functions, troubleshooting features, resolution and accuracy to solve more problems in electronics, plant automation, power distribution, and electro-mechanical equipment. The 87V operates very similar to the classic 87, but with more problem solving power, safety, convenience and impact protection.      FEATURES: Measures •      Unique function for accurate voltage and frequency  measurements on adjustable speed True-rms ac  voltage and current for accurate measurements  on non linear signals •     Built in thermometer conveniently allows you to  take temperature readings without having to carry  a separate instrument •     Motor drives and other electrically noisy equipment •     Measure up to 1000 V ac and dc •     Measure up to 10 A (20 A for 30 seconds) •     10,000 uF capacitance range •     Frequency to 200 kHz and % duty cycle •     Peak capture to record transients as fast as 250 uSec    Features •     Optional magnetic hanger for easy setup and viewing while freeing your hands for other tasks •     Large display digits and 2 level bright white backlight for increased visibility •     Withstands hazardous 8,000 volt spikes caused by        load switching and faults on industrial circuits and complies        with second edition IEC and ANSI electrical safety standards •     Improved sleep mode for long battery life •     Relative mode to remove test lead resistance from low ohms measurements •     Auto and manual ranging for maximum flexibility Additional 87-V features   •     Selectable filter for accurate voltage       and frequency measurements •      4.5 digit mode for precise measurements •      Built in thermometer lets you carry one less tool •       Large display digits and 2 level bright white backlight •      10,000 uF capacitance range for components and motor caps •       Peak capture to record transients as fast as 250 uSec •       Measure up to 1000 V ac and dc •      Measure up to 10 A, 20 A for up to 30 seconds •      Auto and manual ranging for maximum flexibility •     Analog bar graph •      Resistance, continuity and diode test •      Frequency to 200 kHz and % duty cycle •      Min/Max and average recording to        capture variations automatically •      Relative mode to remove test lead resistance •      Improved sleep mode for long battery life •      Access door for battery  without breaking the calibration seal •      Limited lifetime warranty •      Removable holster with built in test lead and probe storage •      Cat IV 600 V and Cat III 1000 V  electrical safety ratings

SPECIFICATIONS:



Function	Range & Resolution	Basic Accuracy
		87V
DC Volts	600.0 mV, 6.000 V, 60.00 V, 600 V, 1000 V	0.05 %
AC Volts		0.7 % (true rms)
DC Current	600.0 uA, 6000 uA, 60.00 mA, 600.0 mA, 6.000 A, 10.00 A	0.2 %
AC Current		1.0 % (true rms)
Temperature (excluding probe)	-200.0 C to 1090.0 C    (-328.0 F to 1994.0 F)	1.0 %
80BK temperature probe	-40 C to 260 C   (-40 F to 500 F)	2.2 C or 2 %
Resistance	600.0 Ω, 6.000 kΩ, 60.00 kΩ, 600.0 kΩ, 6.000 MΩ, 50.00 MΩ	0.2 %
Capacitance	10.00 nF, 100.0 nF, 1.000 uF, 10.00 uF, 100.0 uF, 10000 uF	1.0 %
Frequency	199.99 Hz, 1.9999 kHz, 19.999 kHz, 199.99 kHz	0.005 %











Save when you buy the Fluke 87-5 Combo Pak:





The Combo Pak Save Over $50 in useful accessories for your new Fluke 87-5.
The Pak Includes:
     • TL222 Test Leads
     • TP238 Removable Test Probes
     • AC220 Retractable Alligator Clips
     • Magnet Hanging Strap
     • 80BK Therocouple Sensor
     • C800 Durable Hard Case






Now you can hang you meter almost anywhere with the new Fluke ToolPak accessories kit. ToolPak includes a universal hanger, a magnet, a 17-inch (23 cm) "hook-and-loop" hanger strap.   The universal hanger is designed to fit into the special module on the back of the meter. The universal hanger allows you to hang your meter on a nail, hook or other object. You can add a piece of rope, flexible wire or cable to hang the meter in almost any position.   The 17-inch (23 cm) hook-and-loop strap is used with Fluke's universal hanger to wrap around and connect to a pipe, beam or any other convenient support structure.   And finally, the strong magnet accessory will attach to an electrical panel, a metal doorjamb or any other ferrous-type metal.

Each Meter includes a 9V battery, test leads, ruber holster with stand and manual


What is "Limited Lifetime Warranty"?
Each Fluke 20, 70, 80, 170 and 180 series DMM will be free from defects
in material and workmanship for its lifetime. As used herein, "lifetime" is
defined as seven years after Fluke discontinues manufacturing the product,
but the warranty period shall be at least ten years from date of purchase.



In what way is the warranty limited?

• It does not cover battery or fuses.
• It does not cover abuse or usage outside of specifications.
• It does not cover normal wear and tear of mechanical parts.
• It covers the LCD for 10 years only (state-of-the-art for LCDs).
• It covers original user purchaser only
