Tek Know PC705 Hydraulic Pressure Calibrator up to 10,000 PSIG
|
|
: $5,260.00
OUR PRICE: CALL FOR ASSISTANCE
Item Number: PC705
Manufacturer: Tek Know
Manufacturer Part No: PC705
|
PC705 Hydraulic High Pressure Calibrator
High accuracy and stability is achieved by use of a special thin film strain gauge transducer with built-in temperature compensation. Unlike some other pressure calibrators, accuracy is maintained when decreasing pressure which makes the unit ideal for verification of hysteresis. All units are calibrated in positive as well as in negative direction. Originally designed for use on offshore drilling rigs, these compact and rugged pressure calibrators offer reliable performance under the most severe conditions. The PC705's low weight of only 18 lbs. makes the units ideal for on-site calibration. Each unit is supplied with a calibration certificate after being calibrated against precision pressure equipment traceable to national standards. Full documentation and record keeping of calibrations are easily carried out by use of PreCal Windows ® based software. The PC705 is simple and easy with test pressure being established by the integrated hydraulic pump and calibration pressure being read on the graphical LCD display. There is no need for fragile reference gauges.
Features:
- Ranges from 1000 to 10,000 PSIG
- Built-in pump with fine adjust
- Input for External Sensor
- Accurate to +/-0.03% FS
- mA,V and Switch Test Input
- MIN/MAX, Leak Test, History Log
- Programmable in 12 Engineering Units
- RS-232 Interface with Software
- EEx/IS Approved for Hazardous Areas
Includes:
- Hard Carrying Case
- Hose
- Fittings
- Calibration Certificate
- Software
- Manual
|
|
|
